Longhorn

This chapter describes how to use Longhorn. The example environment is the cluster deployed online in K3s Deployment, and the version in use is v1.5.1.

What Longhorn is: a cloud-native distributed block storage project open sourced by Rancher that provides volumes to Kubernetes through a CSI driver. A volume can have several replicas spread across different nodes, and supports online expansion, snapshots, and backups.
Difference from local-path: local-path stores a volume in a local directory of the node where the Pod runs, while Longhorn decides the volume location itself: replicas can span nodes, and online expansion is supported.

Environment Preparation

Run the following preparation on both the Server and the Agent nodes.

Longhorn attaches volumes to the node that runs the container as iSCSI block devices (so open-iscsi is required), and exporting snapshots to an NFS backup target requires an NFS client. Both are required:

open-iscsi: provides the iSCSI initiator; Longhorn volumes are attached to the node as iSCSI devices;
nfs-common: required when exporting snapshots to an NFS backup target;
jq: required by the dependency check script to parse JSON output.

sudo apt install -y open-iscsi nfs-common jq
systemctl is-active iscsid                 # Must print active

Dependency Check

Longhorn provides an official check script that verifies kernel modules, iSCSI, multipath, and other dependencies item by item and reports a conclusion. Run it once on the Server and on each Agent node:

# Dependency check (Appendix B provides a script for networks in China)
curl -sSfL https://raw.githubusercontent.com/longhorn/longhorn/v1.5.3/scripts/environment_check.sh | bash

If the script reports missing dependencies, install the packages it lists and run it again. Continue only after every check passes.

Deploying Longhorn

Install Longhorn

# Install the storage service
sudo k3s kubectl apply -f https://raw.githubusercontent.com/longhorn/longhorn/v1.5.1/deploy/longhorn.yaml

# Watch the installation progress and wait for the Pods to reach Running one by one (Ctrl+C to quit, which does not affect the installation)
sudo k3s kubectl -n longhorn-system get pods --watch

Verify the Installation

# 1) Are the components ready?
sudo k3s kubectl -n longhorn-system get pods -o wide

# 2) Has the StorageClass been created?
sudo k3s kubectl get sc

# 3) Volumes and replicas (the status of application volumes is also checked here later)
sudo k3s kubectl -n longhorn-system get volumes.longhorn.io
sudo k3s kubectl -n longhorn-system get replicas.longhorn.io -o wide

Acceptance criteria:

Components: longhorn-manager, longhorn-driver-deployer, and csi-* are Running;
StorageClass: longhorn appears in the list with ALLOWVOLUMEEXPANSION set to true;
Volumes: an empty list is normal when no application volume exists yet; once a volume exists, STATE is attached and ROBUSTNESS is healthy.

Longhorn UI

Longhorn ships with a web interface. The default longhorn-frontend Service is a ClusterIP and can only be reached inside the cluster. To open the UI from outside, create a NodePort Service that forwards requests to port 8000 of the UI Pod:

sudo k3s kubectl apply -f - <<'EOF'
apiVersion: v1
kind: Service
metadata:
  name: longhorn-ui-nodeport
  namespace: longhorn-system
spec:
  type: NodePort
  selector:
    app: longhorn-ui              # Matches the label of the longhorn-ui Pod
  ports:
  - port: 80
    targetPort: 8000              # Port the longhorn-ui container listens on
    nodePort: 30880               # A random port in 30000-32767 is assigned if omitted
EOF

Verify and open it:

# Verify on the node; an HTTP 200 and HTML output mean it works
curl -I http://127.0.0.1:30880

Usage Example

This example uses a single YAML file (lh-pool.yaml) to create two independent Longhorn storage pools and to store the two data sets on different nodes. By separating the node that runs the Pod from the storage node that holds the volume replicas, it shows that a Pod can run on one node while its data is stored on another, which means that the Pod location and the data location can be chosen independently.

Manifest contents: 1 Namespace, 2 StorageClass resources, 2 PersistentVolumeClaim resources, and 2 Pod resources; the two StorageClass resources use bmc and sub11 as their storage nodes.
Prerequisites: the Longhorn node used as storage must have node-level and disk-level allowScheduling enabled and a matching storage pool tag and storage directory configured; the node that runs the Pod must be able to pull the busybox:1.36 image.

Check the Storage Pools

First check the scheduling status and tags of the Longhorn nodes:

sudo k3s kubectl -n longhorn-system get nodes.longhorn.io \
  -o custom-columns=NAME:.metadata.name,SCHEDULABLE:.spec.allowScheduling,TAGS:.spec.tags

NAME    SCHEDULABLE   TAGS
bmc     true          []
sub11   false         []

A node used as storage must show SCHEDULABLE as true and must carry a matching pool-<node name> tag.

For example:

bmc     true          [pool-bmc]
sub11   true          [pool-sub11]

If the status or the tags do not meet the requirements, configure them in the next step.

Enable the Storage Pools

Whether a Longhorn node can store replicas is decided by both the node-level and the disk-level allowScheduling, and both must be enabled.

Enabling the disk-level scheduling alone is not enough for Longhorn to create replicas on that node; otherwise the volume may stay in the detached / unknown state, its replicas in stopped, and the Pod may remain in ContainerCreating.

Also give every node a unique storage pool tag:

sudo k3s kubectl -n longhorn-system patch nodes.longhorn.io sub11 --type=merge \
  -p '{"spec":{"allowScheduling":true,"tags":["pool-sub11"]}}'

sudo k3s kubectl -n longhorn-system patch nodes.longhorn.io bmc --type=merge \
  -p '{"spec":{"allowScheduling":true,"tags":["pool-bmc"]}}'

Verify the Storage Pools

Confirm the configuration once more:

sudo k3s kubectl -n longhorn-system get nodes.longhorn.io \
  -o custom-columns=NAME:.metadata.name,SCHEDULABLE:.spec.allowScheduling,TAGS:.spec.tags

Expected result:

NAME    SCHEDULABLE   TAGS
bmc     true          [pool-bmc]
sub11   true          [pool-sub11]

bmc and sub11 now correspond to two storage pools:

Node	Storage pool tag
`bmc`	`pool-bmc`
`sub11`	`pool-sub11`

A StorageClass can later point at the matching tag through nodeSelector to restrict a volume to a specific storage pool.

Configure the Storage Directory

Every Longhorn node has at least one disk, and the path of that disk decides where replicas are actually stored.

By default Longhorn uses:

/var/lib/longhorn/

If the data partition of the device is /userdata, store the Longhorn data directory on that partition, for example:

sudo mkdir -p /userdata/longhorn

Then check the current disk configuration of the node:

sudo k3s kubectl -n longhorn-system get nodes.longhorn.io sub11 \
  -o jsonpath='{.spec.disks}'

Example:

{"default-disk-9fabfb0f4ec0d145":{"allowScheduling":false,"diskType":"filesystem","evictionRequested":false,"path":"/var/lib/longhorn/","storageReserved":2000000000,"tags":[]}}

Where:

default-disk-9fabfb0f4ec0d145: the disk name created automatically by Longhorn; the suffix is random and cannot be derived, so query it before using it.
path: the storage directory actually used by that disk.
allowScheduling: controls whether Longhorn may schedule replicas on that disk.

Use the disk name you queried to change the storage directory:

sudo k3s kubectl -n longhorn-system patch nodes.longhorn.io sub11 --type=merge \
  -p '{"spec":{"disks":{"default-disk-9fabfb0f4ec0d145":{"path":"/userdata/longhorn"}}}}'

For a manually added disk you can choose the disk name yourself, for example userdata-disk on the bmc node.

The disk configuration finally used in this environment is:

Node	Disk name	`path`	`allowScheduling`	`storageReserved`
`bmc`	`userdata-disk`	`/userdata/longhorn`	`true`	8 GB
`sub11`	`default-disk-9fabfb0f4ec0d145`	`/var/lib/longhorn/`	`false`	2 GB

The disk on sub11 is only used to demonstrate node configuration in this example; whether a storage pool is actually usable depends on the real state of the node-level and disk-level allowScheduling.

Create the Application Manifest

Save the following content as lh-pool.yaml:

# -----------------------------
# bmc storage pool
# -----------------------------
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: lh-bmc
provisioner: driver.longhorn.io
allowVolumeExpansion: true
reclaimPolicy: Delete
parameters:
  numberOfReplicas: "1"        # Only the bmc storage pool is used, so the replica count can only be 1
  nodeSelector: "pool-bmc"    # Restrict volume replicas to bmc
  staleReplicaTimeout: "30"
  fsType: "ext4"

---
# -----------------------------
# sub11 storage pool
# -----------------------------
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: lh-sub11
provisioner: driver.longhorn.io
allowVolumeExpansion: true
reclaimPolicy: Delete
parameters:
  numberOfReplicas: "1"         # Only the sub11 storage pool is used, so the replica count can only be 1
  nodeSelector: "pool-sub11"   # Restrict volume replicas to sub11
  staleReplicaTimeout: "30"
  fsType: "ext4"

---
# -----------------------------
# Test namespace
# -----------------------------
apiVersion: v1
kind: Namespace
metadata:
  name: lh-pool

---
# -----------------------------
# PVC: data stored on sub11
# Pod runs on bmc
# -----------------------------
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: data-bmc-write-sub11
  namespace: lh-pool
spec:
  accessModes:
    - ReadWriteOnce
  storageClassName: lh-sub11
  resources:
    requests:
      storage: 1Gi

---
apiVersion: v1
kind: Pod
metadata:
  name: test-bmc-write-sub11
  namespace: lh-pool
spec:
  nodeName: bmc
  containers:
    - name: writer
      image: busybox:1.36
      command:
        - sh
        - -c
        - |
          while true; do
            echo "$(hostname) $(date +%s)" >> /data/who.txt
            sync
            sleep 5
          done
      volumeMounts:
        - name: data
          mountPath: /data
  volumes:
    - name: data
      persistentVolumeClaim:
        claimName: data-bmc-write-sub11

---
# -----------------------------
# PVC: data stored on bmc
# Pod runs on sub11
# -----------------------------
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: data-sub11-write-bmc
  namespace: lh-pool
spec:
  accessModes:
    - ReadWriteOnce
  storageClassName: lh-bmc
  resources:
    requests:
      storage: 1Gi

---
apiVersion: v1
kind: Pod
metadata:
  name: test-sub11-write-bmc
  namespace: lh-pool
spec:
  nodeName: sub11
  containers:
    - name: writer
      image: busybox:1.36
      command:
        - sh
        - -c
        - |
          while true; do
            echo "$(hostname) $(date +%s)" >> /data/who.txt
            sync
            sleep 5
          done
      volumeMounts:
        - name: data
          mountPath: /data
  volumes:
    - name: data
      persistentVolumeClaim:
        claimName: data-sub11-write-bmc

Apply the Manifest

Create the resources with the following command:

sudo k3s kubectl apply -f lh-pool.yaml

Check the StorageClass resources, the PVCs, and the Pods:

sudo k3s kubectl get sc

sudo k3s kubectl -n lh-pool get pvc,pods -o wide

Both PVCs are expected to be Bound, and the two Pods are expected to run on the specified nodes:

NAME                                      STATUS   VOLUME                                     CAPACITY   STORAGECLASS
persistentvolumeclaim/data-bmc-write-sub11   Bound    pvc-97787f2b-e255-4d78-b7dc-63fcf2dccf2b   1Gi        lh-sub11
persistentvolumeclaim/data-sub11-write-bmc   Bound    pvc-8fbd1997-64cf-4224-b6a2-59ca05528a5f   1Gi        lh-bmc

NAME                       READY   STATUS    AGE   IP            NODE
pod/test-bmc-write-sub11   1/1     Running   32s   10.42.0.103   bmc
pod/test-sub11-write-bmc   1/1     Running   32s   10.42.1.62    sub11

Where:

data-bmc-write-sub11 uses lh-sub11, its data is stored on sub11, and the Pod runs on bmc.
data-sub11-write-bmc uses lh-bmc, its data is stored on bmc, and the Pod runs on sub11.

The busybox image is pulled when the Pod runs for the first time, which may take a while. While the image has not finished pulling or the volume has not finished mounting, the Pod may temporarily stay in Pending or ContainerCreating.

Check Where the Data Lands

The storageClassName of a PVC decides which storage pool the volume uses, while the nodeName of a Pod only decides where the Pod runs.

The actual mount node and replica node can be read from the Longhorn Volumes and Replicas:

sudo k3s kubectl -n longhorn-system get volumes.longhorn.io \
  -o custom-columns=NAME:.metadata.name,STATE:.status.state,NODE:.status.currentNodeID

sudo k3s kubectl -n longhorn-system get replicas.longhorn.io \
  -o custom-columns=NAME:.metadata.name,HOSTID:.spec.nodeID

Example:

NAME                                      STATE      NODE
pvc-8fbd1997-64cf-4224-b6a2-59ca05528a5f  attached   sub11
pvc-97787f2b-e255-4d78-b7dc-63fcf2dccf2b  attached   bmc

NAME                                           HOSTID
pvc-8fbd1997-64cf-4224-b6a2-59ca05528a5f-r-363125a9  bmc
pvc-97787f2b-e255-4d78-b7dc-63fcf2dccf2b-r-5a6a5c3f  sub11

Two concepts have to be distinguished here:

Field	Meaning
`NODE`	The node the volume is currently attached to, that is, the mount node used by the Pod
`HOSTID`	The node that hosts the replica, that is, the node where the volume replica is actually stored

The example therefore forms a crossed relationship:

If the nodeSelector in the StorageClass does not match the Longhorn node tags, Longhorn cannot find a suitable storage node and the PVC may stay in the Pending state.

Clean Up the Application

After testing, clean up the resources in the following order:

# Delete the test namespace, which also deletes the PVCs, Pods, and other application resources in it
sudo k3s kubectl delete ns lh-pool

# A StorageClass is a cluster-scoped resource and must be deleted separately
sudo k3s kubectl delete sc lh-bmc lh-sub11

If the storage pools are no longer used, restore the Longhorn node configuration:

sudo k3s kubectl -n longhorn-system patch nodes.longhorn.io sub11 --type=merge \
  -p '{"spec":{"tags":[],"allowScheduling":false,"disks":{"default-disk-9fabfb0f4ec0d145":{"allowScheduling":false}}}}'

To restore the bmc node as well, run:

sudo k3s kubectl -n longhorn-system patch nodes.longhorn.io bmc --type=merge \
  -p '{"spec":{"tags":[],"allowScheduling":false,"disks":{"userdata-disk":{"allowScheduling":false}}}}'
